800W wind turbine components
800W Wind Turbine Generator


Product Description:

Patented aerofoil blade design with true symmetrical and twisted aerodynamic design which ensures rotor capture maximum power from wind (Cp>0.35 in low wind) and operates in amazingly low noise and minimal vibration.

The wind wheel blade with a new technology by precision injection molding, coupled with the optimization of the aerodynamic shape design and structural design, high wind energy utilization factor, an increase of annual power generation.

Product Characteristic:

True symmetrical and balanced aerofoil blade ensure rotor matching with generator perfectly.

Aerodynamic blades designed with over-speed braking system to make sure generator well protected in higher wind.

Reinforced nylon glass-fiber using advanced thermoplastic engineering and precision injection molding technology for higher strength, flexibility and reliability.


Model XM2.5-800W
Rated Output 800W
Peak Output 820W
Rated Voltage off-grid: DC24/48V on-grid: DC48/110V
Start-up Wind Speed 2.0 m/s or 4.5 mph
Cut-in Wind Speed 2.5m/s or 5.6 mph
Rated Wind speed 11m/s or 26.8 mph
Working Temp. range from -40°C to 60°C
Survival Max. wind 50m/s or 110 mph
Over-speed control Electromagnetic & blade aerodynamic braking
Number of Blades 5
Rotor Diameter 1.85 m
Swept Area 3m²
Blade Material Nylon fiberglass reinforced composite
Generator Type Brushless 3-phase PMA with high performance Neodymium Magnets
Tower-top Weight 28 kg
Tower Type self-supporting, guyed, tilt-up tower or rooftop mounting etc.
Controller Type PWM
Applications solar & wind hybrid lighting, on/off-grid power system etc.
Product Life 15 years
Warranty 3 years (optional 5 years)
Years on Market 5 years
Certificate CE, RoHS, ETL, ISO9001:2008, ISO14001
Generator type Three-phase AC permanent magnet generator
Magnetic steel material Magnetic steel material
800W Wind Turbine/Generator
Feature:

1. Start the wind speed is low, high wind energy utilization, small size, good looks,low operating vibration.

2. The installation of user-friendly design, convenient equipment installation,maintenance and repair.

3. Using high-power tracking intelligent microprocessor control, effective regulation of current and voltage.

Benefit:

1. The shell is made of aluminum alloy die-casting, with double bearing carrier, anti-typhoon capacity is stronger, safe and reliable operation.

2. Nylon fiber or FRP blades, high efficiency of anti-wind ability, moves mutely and steadily. After CE / ISO9001: 2000 / ROHS Quality Certification.

3. SCF supercritical generator technology, generator weight only 7.0 kg, generator efficiency over 0.80.

4. Equipped with APS automatic protection system. When wind speed is over 30m/s or output votlage is over rated, protection system will stop wind turbine, when wind speed is suitable, it will release wind turbine again.
